Technical Specification
Serenity Ceramic believes in providing excellent customer service. As one of the leading vitrified companies based in Morbi, India, we are driven by a clear vision and a strong mission. Our dedicated team is self-motivated to deliver outstanding products and provide exceptional experiences, all guided by our core values of humanity.
With more than 25 years of experience in the ceramic sector, we understand that our customers often face challenges when it comes to technical information and basic queries, such as determining the number of tiles they need for their space. To address these concerns and reduce such inquiries, we have provided the following details:
| SR, NO. | CHARACTERISTICS | REQUIREMENT AS PER ISO-13006/EN14411 GROUP Bla | ISO / EN TESTING METHOD |
|---|---|---|---|
| A | DIMENSION & SURFACE QUALITY | ||
| 1 | Deviation in length & width | ± 0.5% | ISO-10545-2 |
| 2 | Deviation in thickness | ± 5.0% | ISO-10545-2 |
| 3 | Straightness in side | ± 0.5% | ISO-10545-2 |
| 4 | Rectangularity | ± 0.5% | ISO-10545-2 |
| 5 | Surface flatness | ± 0.5% | ISO-10545-2 |
| 6 | Color difference | Unlterned | ISO-10545-16 |
| Glossiness | ACCORDING TO SURFACE FINISH | GLOSSOMETER | |
| B | STRUCTURAL PROPERTIES | ||
| 1 | Water Absorption | < 0.50% | ISO-10545-3 |
| 2 | Density (g/cc) | > 2.0 g/cc | DIN 51082 |
| C | MASSIVE MECHANICAL PROPERTIES | ||
| 1 | Modulus of repture | Min. 35 N/mm2 | ISO-10545-4 |
| 2 | Breaking strength | Min. 1300 N | ISO-10545-4 |
| 3 | Impact resistance | As per mfg. | ISO-10545-5 |
| D | SURFACE MECHANICAL PROPERTIES | ||
| 1 | Surface abrasion resistance | As per mfg. | ISO-10545-7 |
| 2 | MOH's hardness | As per mfg. | EN 101 |
| 3 | Skid Resistance (Friction Coefficient) | As per mfg. | ISO-10545-17 |
| E | CHEMICAL PROPERTIES | ||
| 1 | Frost Resistance | Frost Proof | ISO-10545-12 |
| 2 | Chemical Resistance | No Damage | ISO-10545-13 |
| 3 | Stain Resistance | Resistance | ISO-10545-14 |
| F | THERMAL PROPERTIES | ||
| 1 | Thermal Shock Resistance | No Damage | ISO-10545-9 |
| 2 | Thermal Expansion | < 9 x 10-6 | ISO-10545-8 |
| 3 | Moisture Expansion | Nil | ISO-10545-10 |
